Delivers concurrent HD-SDI and Gigabit Ethernet feeds so you can drive SDI displays/recorders and IP streaming in parallel.
CAMHD-1 is a high-definition airborne camera, fully integrated into a rugged, lightweight and aerodynamic housing.
Powered directly by the aircraft 28 VDC, this camera outputssimultaneously 1080p HD-SDI and Ethernet H264 video stream to beinterfaced directly to any ICE/CMS system for entertainment or PARABELLUM® security system.
Designed to be installed on the aircraft tail or belly/fuselage, itshigh-definition 1080 imager works in lightning conditions, from direct sunlight to extreme low light. Camera and window are heated for all-weather operation.
CAMHD-1 is a high-definition airborne camera, fully integrated into a rugged, lightweight and aerodynamic housing.
Powered directly by the aircraft 28 VDC, this camera outputssimultaneously 1080p HD-SDI and Ethernet H264 video stream to beinterfaced directly to any ICE/CMS system for entertainment or PARABELLUM® security system.
Designed to be installed on the aircraft tail or belly/fuselage, itshigh-definition 1080 imager works in lightning conditions, from direct sunlight to extreme low light. Camera and window are heated for all-weather operation.
| P/N Model | Location | Field of view |
|---|---|---|
| 1000-1300-001 | Tail mounted | 55°x31° |
| 1000-1300-006 | Belly mounted | 92°x55° |
| 1000-1300-004 | Belly mounted | 55°x31° |
| 1000-1300-003 | Tail mounted | 92°x55° |
| Temperature and Altitude | 4 |
|---|---|
| Temperature Variation | 5 |
| Humidity | 6 |
| Operational Shocks and Crash Safety | 7 |
| Vibration | 8 |
| Explosive Atmosphere | 9 |
| Waterproofness | 10 |
| Fluid Susceptibility | 11 |
| Sand & Dust | 12 |
| Fungus Resistance | 13 |
| Magnetic Effect | 15 |
| Power Input | 16 |
| Voltage Spike | 17 |
| Audio Frequency Conducted Susceptibility - Power Inputs | 18 |
| Induced Signal Susceptibility | 19 |
| Radio Frequency Susceptibility (Radiated and conducted) | 20 |
| Emission of Radio Frequency Energy | 21 |
| Lightning Induced Transient Susceptibility | 22 |
| Lightning Direct Effect | 23 |
| Electrostatic Discharge | 25 |
| Flammability | 26 |
