Delivers concurrent HD-SDI and Gigabit Ethernet feeds so you can drive SDI displays/recorders and IP streaming in parallel.
CAMHD-2 is a high definition DUAL airborne camera, fully integrated into a rugged, lightweight and aerodynamic fairing.
Powered directly from the aircraft 28 VDC, this camera outputs simultaneously 1080p HD-SDI and Ethernet H264 video stream to be interfaced directly to any ICE/CMS system for entertainment or PARABELLUM security system.
Designed to be installed on the aircraft belly/fuselage, it provides a FWD and AFT view of underneath the aircraft
and its high definition 1080 imager works in lightning conditions from direct sunlight to extreme low-light.
Camera and window are heated for all-weather operation.
CAMHD-2 is a high definition DUAL airborne camera, fully integrated into a rugged, lightweight and aerodynamic fairing.
Powered directly from the aircraft 28 VDC, this camera outputs simultaneously 1080p HD-SDI and Ethernet H264 video stream to be interfaced directly to any ICE/CMS system for entertainment or PARABELLUM security system.
Designed to be installed on the aircraft belly/fuselage, it provides a FWD and AFT view of underneath the aircraft and its high definition 1080 imager works in lightning conditions from direct sunlight to extreme low-light.
Camera and window are heated for all-weather operation.
| Temperature and Altitude | 4 |
|---|---|
| Temperature Variation | 5 |
| Humidity | 6 |
| Operational Shocks and Crash Safety | 7 |
| Vibration | 8 |
| Explosive Atmosphere | 9 |
| Fluid Susceptibility | 11 |
| Sand & Dust | 12 |
| Salt Fog | 14 |
| Magnetic Effect | 15 |
| Power Input | 16 |
| Voltage Spike | 17 |
| Audio Frequency Conducted Susceptibility - Power Inputs | 18 |
| Induced Signal Susceptibility | 19 |
| Radio Frequency Susceptibility (Radiated and conducted) | 20 |
| Emission of Radio Frequency Energy | 21 |
| Icing | 24 |
| Electrostatic Discharge | 25 |
