Optimized as a direct-view screen so crews and passengers can watch content or live feeds without additional repeater hardware.
Display 6.5 is a multi-purpose ruggedized display specially designed for avionics applications. Customizable HMI software can be developed according to your specifications and then downloaded into the display. Several displays can be chained without any additional device (e.g. one external IP camera displayed on all displays), and one storage media can be shared by multiple displays. External camera can be powered using 12 VDC output or Ethernet POE.
This equipment can be installed in the cockpit and cabin areas and is designed to be easily integrated into In-Flight Entertainment and Cabin Management Systems for Cockpit Door Surveillance System (CDSS), full cabin control, or displaying multimedia and camera contents. Tactile buttons with force feedback and a luminosity sensor enable to manually or automatically control the brightness of the screen and to secure operations during the flight.
Display 6.5 is a multi-purpose ruggedized display specially designed for avionics applications. Customizable HMI software can be developed according to your specifications and then downloaded into the display. Several displays can be chained without any additional device (e.g. one external IP camera displayed on all displays), and one storage media can be shared by multiple displays. External camera can be powered using 12 VDC output or Ethernet POE.
This equipment can be installed in the cockpit and cabin areas and is designed to be easily integrated into In-Flight Entertainment and Cabin Management Systems for Cockpit Door Surveillance System (CDSS), full cabin control, or displaying multimedia and camera contents. Tactile buttons with force feedback and a luminosity sensor enable to manually or automatically control the brightness of the screen and to secure operations during the flight.
| Temperature and Altitude | 4 |
|---|---|
| Temperature Variation | 5 |
| Humidity | 6 |
| Operational Shocks and Crash Safety | 7 |
| Vibration | 8 |
| Fluid Susceptibility | 11 |
| Sand & Dust | 12 |
| Magnetic Effect | 15 |
| Power Input | 16 |
| Voltage Spike | 17 |
| Audio Frequency Conducted Susceptibility - Power Inputs | 18 |
| Induced Signal Susceptibility | 19 |
| Radio Frequency Susceptibility (Radiated and conducted) | 20 |
| Emission of Radio Frequency Energy | 21 |
| Electrostatic Discharge | 25 |
